Mirror and TV become one
Séura has engineered and perfected vanity mirrors and displays to work as an integrated system, delivering the highest quality reflection and an astonishing vanishing effect.
VANISHING TECHNOLOGY
Séura Vanity TV Mirrors are purposefully crafted to create excellent mirror reflectivity, while enabling the television to completely disappear when switched off.
True-to-life reflection
Séura's specially formulated vanishing vanity glass is designed to closely resemble traditional silver mirror, providing excellent mirror reflectivity and deliver a true-to-life reflection.
NOW BRIGHTER THAN EVER
Séura offers the highest quality Vanity TV Mirror viewing experience with displays that now appear 25% brighter.
Customization
Unique design configuration options include display size, mirror size, framing, technology upgrades and more.
Add Vanity Lighting
Customize your TV Mirror with industry-leading LED lighting.
Select a frame
Séura’s collection of designer frames complement any designed space from classic to modern. Select from over 100 designs.
Specialized electronics for a clean design
Unlike most TVs, Séura TVs are engineered with anticipatory cable management. Inputs and outputs facing up instead of straight back to allow for a thinner profile and easy cord concealment.
| Specification | |
|---|---|
| IDEAL SPACES | Bathroom |
| DISPLAY SIZES (DIAGONAL) | 10 inch, 19 inch, and 27 inch |
| MIRROR GLASS | Vanishing Vanity Glass |
| STANDARD MIRROR SIZES | Widths: 24″, 33", 45" Height: 36″ |
| Customizations | |
| CUSTOM DESIGN OPTIONS | Polished bevel, custom frame, ambient lighting, light diffuser, TV screen placement, mirror shape, custom holes, matching mirrors |
| CUSTOM TECHNOLOGY OPTIONS | Brilliant LED Technology™ lighting, dimmable lighting, LED nightlight, mirror defogger |
| CUSTOM FUNCTIONALITY OPTIONS | Fingerprint protection coating, tamper-free security hardware*, safety mirror backing |
| MAXIMUM MIRROR SIZE | Up to 94″ w x 70″ h or 70″ w x 94″ h |
| MINIMUM MIRROR SIZE | 18 ½” W x 19” H (Recessed); 20 ½” W x 22 ½” H (Surface) |
| Video | |
| VIEWABLE SCREEN SIZE | 8 7∕8" w x 5" h |
| DISPLAY RESOLUTION | 1024 x 600 |
| ASPECT RATIO | 16:10 |
| CONTRAST RATIO | Typical 4000:1 |
| TUNER | ATSC, NTSC, QAM |
| RESPONSE TIME | 8 ms |
| VIEWING ANGLE | 178° Horizontal/Vertical |
| POWER CONSUMPTION | DC 19V 10W / .083A |
| Integration | |
| HDMI | 2 |
| COMPONENT YPBPR | 1† |
| COMPOSITE (AV) | 1† |
| VGA | 1 |
| S-VIDEO | 1 |
| RF COAXIAL ANTENNA | 1 |
| USB | 1 |
| RS-232 | 1† |
| IR INPUT | 1 |
| IR OUTPUT | 4 |
| Audio | |
| PC AUDIO IN | 1 |
| FIXED LINE OUT | 2 |
| PHOENIX TYPE SPEAKER OUTPUT | 2 x 5W @8Ω/ channel |
| INTERNAL SPEAKERS | 2 x 10W |
| Installation | |
| MOUNT OPTIONS | Integrated Surface Mount or Integrated Recessed Mount |
| SURFACE MOUNT OFF-WALL DISTANCE | 1 1/2" |
| RECESSED MOUNT IN-WALL DEPTH | 3/4" |
| RECESSED MOUNT WALL OPENING SIZE | 22" w x 26" h |
| RECESSED MOUNT VENT GAP | 1/4" |
| OTHER | |
| CERTIFICATIONS AND COMPLIANCE | CE, FCC |
| WARRANTY | Séura’s Labor for three (3) years; Mirror, Glass, Structure, Frame, and Assembly for three (3) years; TV including remote and power supply for two (2) years. |
| REMOTE | Séura IR Remote Control |
