Rotel 5.0 Channel Mutichannel Amplifier - RMB1555B
Rotel 5.0 Channel Mutichannel Amplifier - RMB1555B
Rotel 5 Channel Home Theater Amplifier - RMB1555S
You may also like
With only slightly less power than its big brother, the RMB-1555 retains a very robust power supply to deliver 5 x 120 Watts per channel to medium and large home theaters.
- 5 x 120 Watts of robust power
- Class AB amplifier design
- High quality slit foil capacitors made in Britain
- Rack ears included
- 12 volt trigger input
Engineered with care.
Product Description
The RMB-1555 is a remarkable multichannel amplifier with power output conservatively rated at 120 Watts per channel into 8 ohms (all channels driven!). With all but the most demanding speakers located in extraordinarily large rooms, the RMB-1555 exerts the kind of precise control that presents both nuance and bombast correctly from the faintest flute overtones to the subterranean rumble of an approaching apocalypse.
The RMB-1555 employs a high current, toroidal transformer matched to discrete output transistors with their higher thermal stability and freedom from the designed-in compromises that characterize their integrated circuit cousins. The Class AB amplifier configuration assures the best balance between power output and thermal efficiency.
| Specifications | |
|---|---|
| DIMENSIONS (W × H × D) | 431 × 188 × 454mm 17" × 7.5" × 17.9" |
| FRONT PANEL HEIGHT | 4U / 176.8mm (7") |
| POWER REQUIREMENTS | 120V, 60Hz |
| POWER CONSUMPTION | 650W |
| STANDBY POWER CONSUMPTION | 0.5W |
| NET WEIGHT | 21.8kg (48lbs.) |
| BTU RATING (4Ω, 1/8th power) | 1683 BTU/h |
| CONTINUOUS POWER OUTPUT | 120W/Ch (All channels driven, 8Ω) |
| TOTAL HARMONIC DISTORTION (THD) | (20Hz–20kHz) <0.03% |
| FREQUENCY RESPONSE | 10Hz - 100kHz +0.5, -3dB |
| S/N RATIO (IHF "A" Weighted) | 116dB |
| GAIN | 26.5dB |
| INTERMODULATION DISTORTION (60Hz:7kHz, 4:1) | <0.03% |
| DAMPING FACTOR | 180 |
| SPEAKER IMPEDANCE | 4Ω minimum |
| INPUT SENSITIVITY | 1.5V |
| INPUT IMPEDANCE | 12kΩ |
