Marantz Network Integrated Amplifier in Black - Model 60n (B)
Marantz Network Integrated Amplifier in Silver Gold - Model 60n (SG)
Marantz Network Integrated Amplifier in Black - Model 60n (B)
You may also like
MODEL 60n is a network integrated amplifier engineered for exceptional hi-fi performance and comprehensive connectivity. Stream in high-resolution via HEOS® Built-in, connect your CD player or turntable and complete your hi-fi system with the speakers of your choice, or an optional subwoofer.
- 60W per channel
- HEOS® Built-in
- HDMI ARC
- Marantz HDAM® circuits
- Hi-Res audio support
- CD and MM phono inputs
The perfect blend of performance and connectivity
MODEL 60n is a network integrated amplifier engineered for exceptional hi-fi performance and comprehensive connectivity.
Superb Marantz Sound
Sound Master tuned and engineered to bring you all the texture, nuance, and clarity of the Marantz signature sound.
High Resolution Streaming
Sound Master tuned and engineered to bring you all the texture, nuance, and clarity of the Marantz signature sound.
Build Your Hi-fi System
Wide range of connections, including for a CD player and turntable, enable you to build a comprehensive hi-fi system.
Enhanced TV Sound
Enjoy superior TV sound for your favorite movies and shows and enhance your gaming experience with MODEL 60n’s HDMI ARC connection.
Marantz Industrial Design
Intuitive operation, designed with robust yet refined materials and available in two colorways: black and silver-gold.
For the Soundtrack of Your Life
HEOS® Built-in has a search feature that lets you find and stream from the world’s leading music platforms, including TIDAL, Pandora, and Amazon Music HD.
Search for Songs Across Platforms
HEOS® Built-in has a search feature that lets you find and stream from the world’s leading music platforms, including TIDAL, Pandora, and Amazon Music HD.
Your Whole Home in One Place
HEOS-enabled devices allow you to control multiple rooms, all with the HEOS app.
Hi-Resolution Streaming
Use your HEOS-enabled Marantz devices to access high-resolution music streaming and discover a whole new way to love your favorites.
| AMPLIFIER | |
|---|---|
| Topology | Class A/B |
| Power Output (8 / 4 Ohm RMS) | 60 W / 80 W |
| Number of Terminals | 2 |
| Speaker Terminals | Marantz SPKT-1+ |
| Speaker A / B | No |
| PSU Transformer | Toroidal |
| Channels | 2 |
| Audio Components and Technologies | |
| Current Feedback Topology | Yes |
| HDAM Version | SA3, SA2 |
| High Grade Audio Components | Yes |
| Customised Components | Yes |
| Symmetric PCB Layout | Yes |
| Aluminium Extrusion Heat Sink | Yes |
| Copper Plated Chassis | No |
| Marantz Musical Digital Filtering | No |
| Linear Drive Power Supply | Yes |
| BI-AMP and Multichannel Option | No |
| Shottky Diodes | Yes |
| Control | |
| D-Bus | Yes |
| DAC | |
| Digital Inputs | Coaxial, Optical, USB-A |
| Max PCM Sample Rate | 192 kHz / 24-bit |
| Max DSD Sample Rate | DSD 4X (11.2 MHz) |
| HDMI | 1 ARC |
| HEOS | |
| Streaming Technologies | Bluetooth, Airplay 2, Roon Ready, Spotify Connect, Tidal Connect |
| Streaming Services (subject to change and local availability) | Tidal (Hi Res), Deezer (Hi Res), Amazon Music HD, Pandora, TuneIn, iHeartRadio, SoundCloud, SiriusXM, AWA, Mood:Mix, Qplay, Sony HiRes |
| HEOS Multiroom and Streaming | Yes |
| Lossy Formats | MP3, WMA, AAC |
| Lossless Formats | DSD/DSF, FLAC, ALAC, WAV, AIFF |
| Gapless Playback | Yes |
| HEOS App | iOS, Android |
| Network | |
| Wi-Fi / Wired LAN | Yes / Yes |
| OTHER | |
| Display | Low-Noise OLED Monochrome |
| PREAMP | |
| Phono EQ | MM Standard |
| Tuner: FM / AM | No |
| Audio Adjustments | Yes |
| Power Amp Direct | 4 |
| Balanced In / Out | No / No |
| Preamp Outputs | 1 |
| Subwoofer Output | 1 Mono |
| Headphone Out | Yes |
| Specifications | |
| Frequency Response | 5 Hz-100 kHz |
| Total Harmonic Distortion | 0.02 % |
| Damping Factor | 100< |
| Input Sensitivity: MM | 2 mV / 47 kOhm |
| Signal to Noise Ratio: MM/MC | 87 dB / - |
| Input Sensitivity: High Level | 190 mV / 20 kOhm |
| Signal to Noise Ratio: High Level | 113dB(2V input) |
| Treble Control | ± 10 dB at 10kHz |
| Bass Control | ± 10 dB at 50Hz |
| Metal Front Panel | Yes |
| Power Consumption in W | 220 |
| Standby Consumption in W | 0.3 |
| Auto Power Off | Yes |
| Detachable Power Cable | Yes |
| Remote Control | RC006PM |
| System Remote Function | Yes |
| Maximum Dimensions (W x D x H) mm | 442 x 431 x 129 |
| Carton Maximum Dimensions (W x D x H) mm | 527 x 517 x 255 |
| Carton Weight (inc. product) in kg | 15.5 |
| Maximum Dimensions (W x D x H) in | 17.4 x 17 x 5.1 |
| Weight in LBS | 28.1 |
| Carton Maximum Dimensions (W x D x H) in | 20.8 x 20.4 x 10.1 |
| Carton Weight (inc. product) in LBS | 34.3 |
