Marantz 9.5 Channel AV Receiver with 125 Watts Per Channel in Black - Cinema 40
Marantz 9.5 Channel AV Receiver with 125 Watts Per Channel in Black - Cinema 40
Marantz 9.5 Channel AV Receiver with 125 Watts Per Channel in Silver Gold - Cinema 40 (SG)
You may also like
PREMIUM 9.4 CHANNEL | 125-WATTS-PER-CHANNEL AV RECEIVER
Premium 9.4 channel 125-watts-per-channel amplification, Dolby Atmos, DTS:X Auro 3D, and 8K Ultra HD plus HEOS® Built-in streaming. CINEMA 40 is a statement piece and reference level A/V Receiver.
Excellence Only Begins with Performance
Built upon decades of rich heritage, designed with timeless style, and engineered for utmost performance, Marantz CINEMA Series are the foundation of the world's most demanding home theaters.
Key Features
Peerless Performance
Immersive spaciousness, warm and rich tone, extraordinary detail and lifelike dynamics are legendary hallmarks of the Marantz sound.
Technology Leader
CINEMA 40 comes complete with the latest immersive audio formats, 8K video, room optimization, streaming, and more technology to simplify and elevate your enjoyment.
Exquisite Slimline Design
A modern expression of timeless design principles, CINEMA 40 features the iconic Marantz porthole, premium materials, and subtle sidelights that illuminate the front panel.
Believe in Quality
Performance
The Marantz Sound Master meticulously tuned CINEMA 40 for amazing performance with careful parts selection to create the Most Musical Sound in your home.
Style
Excellence is heard and seen. CINEMA 40 is meticulously crafted with authentic materials in a modern style befitting its rich heritage and stunning performance.
Customizability
Thoughtfully curated connectivity options and finetuning ability allow you to make CINEMA 40 your own.
Effortless
Included remote, accessible front-panel controls, and an intuitive on-screen setup process make you feel like an expert user right away.
| GENERAL | |
|---|---|
| What's in the box | Main unit, remote control, batteries, wire labels, quick start guide, Audyssey microphone, microphone stand, 2 External Detachable Antenna, AC cord |
| Weight in lbs. | 33.3 |
| Maximum Dimensions Antenna:Horizontal:(W x D x H) in inches Antenna:Vertical :(W x D x H) in inches W/o Antenna:(W x D x H) in inches | 17.3 x 16.2 x 7.3, 17.3 x 16.2 x 10, 17.3 x 15.8 x 7.3 |
| Network Standby Consumption in W | Less than 2.0 |
| CEC Standby Consumption in W | 0.5 |
| Standby Consumption in W | 0.2 |
| Power Consumption No-Sound (ECO on/off) in W | 65 / 110 |
| Power Consumption in W | 710 |
| System Remote Control | RC048SR |
| Metal Front Panel | Yes |
| Available Colors | Black/Silver-Gold |
| OTHERS | |
| Sleep Timer | Yes |
| Auto Power off | Yes |
| ECO Mode | Yes |
| Firmware Update by Network / USB | Yes / Yes |
| Smart Select on Remote | Yes |
| Setup Assistant | Yes |
| GUI Languages | 9 |
| Front Display | 2 line FLD + port hole OLED |
| SMART HOME INTEGRATION AND CONTROL | |
| IR Flasher In | Yes |
| Marantz Remote Bus | Yes |
| DC Trigger Output | 3 |
| HDMI Diagnostics | Yes |
| Zone HDMI Output from HDMI Source | Yes |
| Control Connectivity | IP Control / RS232 Control / Web Control / App Control |
| Zone Audio Output: Speaker / Preout | Yes / Yes |
| Multi-Room zones | 3 |
| Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog | 2 Ch / 2 Ch / Yes / Yes |
| HEOS Link Compatibility: IR/ IP | Yes / Yes |
| HEOS Multi-Room Integrated | Yes |
| App for Smart Phones & Tablets (iOS & Android) | Marantz AVR Remote App, HEOS |
| Voice Assistant Compatibility | Alexa / Google Voice Assistant / Apple HomePod |
| Network Connectivity | |
| Wi-Fi (include version / band) | Yes |
| Bluetooth (Include version) | Yes |
| Bluetooth Re-transmit for Bluetooth headphones | Yes |
| Ethernet Ports | Yes |
| STREAMING SERVICES | |
| Roon tested | Yes |
| SiriusXM | Yes |
| Other Streaming Services * | Amazon Music HD/ Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / SoundCloud / Mood Mix |
| Spotify* | Spotify Connect |
| AirPlay Audio Streaming | Airplay 2 |
| Internet Radio | TuneIn |
| HEOS Multi-room and Streaming | Yes |
| MUSIC FILE SUPPORT | |
| Network Audio Sharing | Yes |
| Compressed Audio Enhancer: MDAX2 | Yes |
| Gapless Playback | FLAC, WAV ,ALAC ,DSD |
| DSD Audio | 2.8MHz / 5.6MHz |
| Lossless formats | FLAC HD 192/24 / WAV 192/24 / ALAC 192/24 |
| Lossy Formats | MP3 / WMA / AAC |
| Acoustic / Room Correction | |
| Optimized Bass Redirection | Yes |
| Bass Sync | Yes |
| Variable Cross Over | Yes |
| Audyssey LFC | Yes / Yes |
| Dirac Live Upgradability | Yes |
| Audyssey | MultEQ XT32 |
| Audyssey Dynamic EQ / Dynamic Volume | Yes / Yes |
| PERFORMANCE TECHNOLOGIES | |
| Clock Jitter Reducer | Yes |
| Pure Direct Mode | Yes |
| Gold Plated RCA Terminals | Yes |
| Toroidal Power Supply Transformer | No |
| Hyper Dynamic Amplifier Modules (HDAM) (List version) | Yes |
| Copper Plated Chassis | No |
| HDMI | |
| DSD Audio over HDMI | Yes |
| Auto LipSync | Yes |
| HDMI Pass-Through in Standby Mode | Yes |
| CEC | Yes |
| Variable Refresh Rate / Quick Frame Transport | Yes / Yes |
| ALLM (Auto Low Latency Mode) Pass-through for gaming | Yes |
| Audio Return Channel | ARC, eARC |
| Video Dynamic Range | HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR |
| HDMI Upscaling | 1080P/4K to 8K |
| Max resolution @ framerate | 8K @ 60Hz, 4K @ 120Hz |
| Analog to HDMI Video Conversion | Yes |
| HDMI Outputs: Main / Zone | 2 / 1 |
| HDCP2.3 support | Yes |
| Total HDMI Inputs / No. Support 8K | 7 / 7 |
| INPUTS/OUTPUTS | |
| USB Audio / Made for iPod / Made for iPhone | Yes / No / No |
| AM/FM Tuner | Yes |
| Front Inputs | USB-A |
| Multi-Room Speaker Terminal | assignable |
| Speaker A / B | assignable |
| Subwoofer Out | 4 (independent) |
| 7.1 multichannel input | No |
| Number of Speaker Terminals | 11 |
| Multichannel Preamp Out | 11.4 |
| Digital In: Optical / Coaxial | 2 / 2 |
| Multi-Room Out: analog / digital | 2 / 0 |
| Phono (MM) In | Yes |
| Multi-Room Video Out via HDMI | Yes |
| Analog In / Fixed Level Out | 5 in / 0 out |
| Component In / Out | 1 / 0 |
| HDMI In / Out | 7 / 3 |
| Composite In / Out | 2 / 0 |
| MULTICHANNEL SURROUND TECHNOLOGIES | |
| Max Number of Processing (Preamp) Channels | 11.4 |
| Other | IMAX Enhanced, Auro-3D, 360 Reality Audio, MPEG H, Audyssey DSX, Multichannel Stereo2 |
| Dolby | Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround |
| DTS | DTS HD Master, DTS:X, DTS Neural:X, DTS Virtual:X |
| POWER AMPLIFIER | |
| Current Feedback Topology | Yes |
| Bi-Amp Drive | assignable |
| Amplifier Topology | Class A/B |
| Discrete Power Amplifier | Yes |
| 70% Guarantee | Yes |
| Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive) | 125 W |
| Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) | 165 W |
| Power Output (6 ohm, 1 kHz, 10% 1ch Drive) | 235 W |
| Number of Powered Channels | 9 |
| Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) | - |
